Simply connect to any Ethernet port. THAT’S IT.

Your camera is now a source for all NDI compatible systems and software on your network.

About NDI

NDI is in use in millions of devices allowing multiple video systems to identify and communicate with one another over IP. NDI can encode, transmit and receive many streams of high quality, low latency, frame-accurate video and audio in real time. This benefits any network-connected video device, including video mixers, graphics systems, capture cards, and many other production devices. This makes it possible to exponentially increase the number of sources available for live production switching, without directly attaching to devices, changing locations, or investing in expensive, high-bandwidth networks that simply replace SDI-based workflows.

Technical Specifications

• NDI output over IP via Ethernet connection
• 3G-SDI or HDMI video output
• Native support for HD resolutions up to 1080p 60
• Support for tally via NDI
• Remote control & monitoring via Web-based interface
• 20x optical zoom
• Power over Ethernet via POE+ (802.3at)
• Mounting bracket included
• Dimensions: 6.9 x 7.2 x 7.2 in (175 x 183 x 183 mm)
• Weight: 4.0 lbs (1.8 kg)

Video Output	Video OutputVideo output via NDI®|HX, 3G-SDI, and/or HDMI
Video Formats	Video Formats1080p: 60, 59.94, 50, 30, 29.97, 25 1080i: 59.94, 50 720p: 60, 59.94, 50, 25
Lens	Zoom: 20x Optical / 12x Digital Focal Length: 4.7mm to 94mm Aperture: F1.6 to F3.5
Shutter Speed	1/1 to 1/10,000 sec
Rotation Speed	Rotation Speed300°/sec maximum
Panning Angle	-170° to +170°
Tilting Angle	Tilting Angle-30° to +90°
Horizontal Viewing Angle	63°
Flip	FlipIntegrated image flip and mirror function for flexible installation
Preset Positions	128
Minimum Illumination	1.0 lux (F1.6, 50IRE, 30fps)
Minimum Object Distance	300mm (wide) / 1500mm (tele)
Audio Input	3.5mm stereo audio input (line)
Tally	Tally support via NDI®|HX
Focus System	Auto, Manual
White Balance	Auto, Manual, Indoor, Outdoor, One-Push
Gain Control	Auto, Manual
Exposure Control	Auto, Manual
Sensor	1/2.8” CMOS, 2 megapixels
S/N Ratio	>50dB
User Interface	Remote configuration, control, and monitoring via Web-based user interface or Vizrt NDI® Studio Monitor application
Control Protocol	NDI®
Networking	1 x RJ45 port for 10/100 M Ethernet networking
Power	Power over Ethernet via POE+ (802.3at) or included DC 12V 1A external supply
Physical	Dimensions: 6.9 x 7.2 x 7.2 in (175 x 183 x 183 mm) Weight: 4.0 lbs (1.8 kg)

Vizrt NDI® PTZ Camera Features

Imagine the possibilities of a camera that can serve as a live video input for any NDI®-compatible hardware or software—from anywhere on your network. Introducing the Vizrt NDI® PTZ Camera, the faster, easier, and better way to acquire live video.

Multicast Mode

Optionally allow multiple destinations to receive video from your NDI® PTZ Camera without individual point-to-point connections to conserve network bandwidth.

NDI® Output

Acquire and deliver video to the network in full HD, with NDI® output via NDI®|HX and native support for resolutions up to 1080p at 60 frames per second.

Power over Ethernet

Streamline installation and reduce cabling complexity, optionally eliminating the need for a separate power supply connection with support for Power over Ethernet via POE+ (802.3at).

Pan-Tilt-Zoom

Perform real-time pan, tilt, and zoom camera movements with motor-driven PTZ camera control and configurable preset positions.

3G-SDI and HDMI Output

Optionally acquire and deliver video into conventional workflows with support for 3G-SDI and HDMI hardware output.

Program and Preview Tally

Receive tally notification from compatible NDI® devices via physical LEDs when video output from your NDI® PTZ Camera is visible on Program and/or Preview.

Remote Control & Monitoring

Operate camera controls, monitor video, manage login credentials, and configure audio, video, and network settings from any compatible networked device using the Web-based user interface or Vizrt NDI® Studio Monitor.

Remote Recording

Capture live NDI® PTZ Camera video remotely from any compatible computer or device using Vizrt NDI® Studio Monitor.

Video Bandwidth

Select from High, Medium, and Low bandwidth output to accommodate your specific network configuration and traffic.

Video Settings

Manage NDI® PTZ Camera options to include exposure, focus, iris, shutter speed, white balance, wide dynamic range, and more with configurable video settings.

Audio

Present high-quality audio, with support for mic and line level audio input, and adjustable volume control.

NDI® Virtual Input

Designate your NDI® PTZ Camera as the video input source in popular desktop video applications like Google Hangouts, GoToMeeting, Skype, Skype for Business, WebEx, Zoom, and more, via the included software driver.

Network Identification

Easily identify your NDI® PTZ Camera on the network with the ability to apply custom device and channel names.

Free Firmware Updates

Download and install free firmware updates to ensure your NDI® PTZ Camera is equipped with the latest features, capabilities, and performance enhancements.
*Specifications subject to change without notice.
